The
Daisy Seed
Cost: from $22 US
Embedded platform for audio development
Stereo audio IO - 96kHz / 24-bit audio hardware (AC-Coupled)
Programmable in: C++, Arduino, Max/MSP gen~, Pure Data
x31 GPIO, x12 ADC inputs (16-bit), x2 DAC outputs (12-bit, DC-Coupled)
ARM Cortex-M7 MCU, running at 480MHz
64MB of SDRAM for up to 10 minute long audio buffers, 8MB external flash
SD card interface, PWM outputs, and various serial protocols for external devices (SPI, UART, SAI/I2S, I2C)
Must use their dsp libraries ... difficult to use own C++ libraries
